Meishuo Fpd360f40 Normally Closed Micro Magnetic Solenoid Valve 12 V for Water

Meishuo Fpd360f40 Normally Closed Micro Magnetic Solenoid Valve 12 V for Water

Meishuo FPD360F40 normally closed micro magnetic solenoid valve 12v for water Dimensions: Hot Selling Items Type1: Name:
Send to us
Basic Info.
Model NO. FPD360F40
Pressure Low Pressure
Usage Flow Control
Application Household Usage
Rated Voltage DC 12V 24V 36V AC110V 220V 50/60Hz
Pressure Range 0.2~0.8bar
Outlet G1/2
Flow Rate > 3L/Min
Hydraulic Pressure 0.3MPa
Standard or Nonstandard Can Provide by Customized
Power Solenoid
Structure Solenoid Valves
Channel Straight Through Type
Inlet G1/2
Function Electric Valves
Nominal Pressure 0.2~0.8bar
Driving Mode Electric
Transport Package Carton/Pallet
Specification 100 PCS/Carton
Trademark Meishuo/OEM
Origin Zhejiang, China
HS Code 8481804090
Production Capacity 100000 Piece/Pieces Per Day
Product Description

Meishuo FPD360F40 normally closed micro magnetic solenoid valve 12v for water


Meishuo Fpd360f40 Normally Closed Micro Magnetic Solenoid Valve 12 V for Water

Meishuo Fpd360f40 Normally Closed Micro Magnetic Solenoid Valve 12 V for Water

Detailed Information

Rated Voltage

DC12V 24V 36V AC

110V 220V 50/60HZ

Pressure range

0.02~0.8MPa

Operate Life

>100000 OPS

Spacing

25mm*25mm

Inlet

13.7mm pagoda

Outlet

13.7mm pagoda

Hydraulic Pressure

0.003MPa

Flow Rate

>1.2L/min


Dimensions:

Meishuo Fpd360f40 Normally Closed Micro Magnetic Solenoid Valve 12 V for Water

Hot Selling Items

Type1:

Name: FPD360E Plastic Water Valve

Rated Voltage: DC12V 24V 36V AC110VAC 220VAC 50/60H

Pressure Range: 0.02~0.8MPa

Operate Life: >100000 OPS

Inlet : G1/2" external Thread

Outlet: G1/2" external Thread

Hydraulic Pressure: 0.3MPa

Flow rate: >5L/min

Type2:

Name: FPD360F Plastic Inlet Solenoid Valve

Rated Voltage: DC12V 24V 36V AC110V 220V 50/60HZ

Pressure Range: 0.02~0.8MPa

Operate Life: >100000 OPS

Inlet: G1/2" External Thread

Outlet : G1/2" external Thread

Hydraulic Pressure:0.3MPa

Flow Rate: >5L/min

Type3:

Name: FPD360A Plastic Inlet Solenoid Valve
Rated Voltage: DC12V 24V 36V AC110V 220V 50/60HZPressure Range: 0.02~0.8MPa
Operate Life: >100000 OPSInlet: 1/4" Quick connect fittingOutlet : 1/4" Quick connect fittingHydraulic Pressure:0.3MPaFlow Rate: >3L/min

Meishuo Fpd360f40 Normally Closed Micro Magnetic Solenoid Valve 12 V for Water


Meishuo Fpd360f40 Normally Closed Micro Magnetic Solenoid Valve 12 V for Water

OUR SERVICES & STRENGTH

PRE-SALES SERVICE

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

AFTER-SALES SERVICE

*If you have any problems, we have a group of professional engineers to assist you in any time.

1.Advanced Manufacturing Technology

2.Authoritative certification

3.Quality assurance

Why Choose Us

Our customers come from all over the world

* Excellent Quality

* Good Feedback

* Quick Response

* Excellent Service

* On Time Shipment

*All products are 100% Tested


FAQ

Q1. Can I have a sample order for water valve?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.Q2. What about the lead time?
A:Sample needs 3-9 days, mass production time needs 1-2 weeks for order quantity more thanQ3. Do you have any MOQ limit for Water valve order?
A: Low MOQ, 1pc for sample checking is availableQ4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.Q5. How to proceed an order for Water Valve?
A: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order.Fourthly We arrange the production.Q6. Is it OK to print my logo on water valve product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
